10 Inch Rugged Display ARD10
10” Rugged Display for C5ISR Platforms
| Main Features |
|---|
| ▸ Extremely Small Bezel Dimensions |
| ▸ Low Weight |
| ▸ Customer Defined Bezel Buttons |
| ▸ NVG Compatibility (Option) |
| ▸ High Brightness (Option) |
| ▸ Military Connectors |
| ▸ Wide Range for Environmental/EMI |
| ▸ Fully Enclosed Unit (IP66), Convection Cooling |
| ▸ Rugged AR Touch Screen (Option) |
| Applications |
|---|
| ▸ Fixed & Rotary Wing Aircraft |
| ▸ Naval & Maritime Vessels |
| ▸ Military Ground Vehicles |
| ▸ Transportation |
| ▸ Oil & Gas |
Login to Download Datasheet
Overview
ArgonFDS offers a 10.1” & 10.4” rugged display suitable for Command & Control applications where space is at a premium, such as in combat & tactical vehicles, mobile shelters, and tight naval workspaces.
The ARD10’s small bezel size, flexible mounting configurations, configurable I/O, and universal AC/DC power supply make it a valuable solution for many mission-critical applications.
The ARD10 is a full-featured combat-ready display with various standard options. ArgonFDS is prepared to customize the display to ensure the product meets your specific requirements.
Moreover, ArgonFDS prides itself on working collaboratively with customers to precisely achieve their desired solution. Our company has a proven track record of providing high-quality, reliable, and long-lasting products, earning us a trusted reputation in aerospace & defense.
Specifications
| Optical | |
|---|---|
| Viewable Area | 10.4” Diagonal |
| Display Type | TFT LCD w/ LED Backlight |
| Resolution | 640x480 (VGA), 800x600 or 1024x768 (XGA) |
| Contrast Ratio | >1400:1 |
| Brightness | 400 Nits Standard, High Brightness option up to 750+ nits |
| Touch Screen | Ruggedized, Analog Resistive |
| NVG | Optional NVG Compatibility |
| Overall Unit | |
|---|---|
| Dimensions (Typical) | 10.0" x 8.0" x 1.5" |
| Weight | 6 +-lbs |
| Power Input | 18 to 36VDC or 110/220, 44Hz to 440 Hz VAC Input |
| Power Consumption | 25W Typical |
| I/O | RGB/DVI/RS-170, Remote Control - RS232/USB |
| Connectors | MIL Circular, D Sub or Specify |
| Enclosure | Aluminum, Enclosed (No Openings) |
| User Controls | On/Off, Day/Night, OSD, Brightness, Bezel Buttons |
| Environmental | |
|---|---|
| (Designed to meet, but is not limited to,the following selected specifications) | |
| Operating Temp | -10oC to +55oC (-40oC optional) |
| Storage Temp | -40oC to +71oC |
| Shock | Crash Safety, Bench Handling, MIL-STD-810G, Method 516.6 |
| Vibration | Sine on Random, MIL-810E, Method 514.6, Proc 1, Cat 7 |
| EMI/EMC | Full suite of MIL-STD-461 (Performed on AT version) |
| Altitude | 40k ft Operational/Non-Operational |
| Salt Fog, Sand/Dust | MIL-STD-810F, Method 510.5, Proc I & II (IP66) |
